| Specification | Details |
|---|---|
| Manufacturer | Telemecanique |
| Model Number | LC1 D09 01 |
| Additional Model Numbers | LC2D0901, LC2D0901B7 |
| Description | 3-pole Reversing Contactor |
| Voltage | 24V 50/60Hz |
| Standards | IEC 947, EN 60947, NFC 63110, VDE 0660, BS 5424 |
| Thermal Current (Ith) | 25A |
| Rated Insulation Voltage (Ui) | 1000V |
| Impulse Withstand Voltage (Uimp) | 8kV |
| Continuous Current | 20 A |
| AWG | 10-18 Cu 75°C |
| Torque | 7 Lb.In. |
| Auxiliary Contact Ratings | A 600 P 600 |
| Catalog Number | 0378015.153 |
| Power Rating | 4kW-400V, 5HP-460V |
| Reference | 992.02.04.003 |
| Country of Origin | France |
| Weight | 730 gm |
The Telemecanique LC1 D09 01 3-pole Reversing Contactor is a basic tool in the industrial application for motor control and ensures safe and reliable reversing operations for a three-phase motor. This LC1 D09 01 is rated at 24V and can be used with 50/60Hz. Thus, it can be easily adapted to any type of electrical system.
Key Features and Specifications:
- 3-Pole Configuration: The LC1 D09 01 contactor features a 3-pole design, making it suitable for reversing operations in three-phase motor systems, ensuring smooth and safe direction switching.
- Voltage and Frequency: Operates efficiently at 24V AC and supports 50/60Hz power systems, offering flexibility for use in global applications.
- High Durability and Performance: Constructed with high-quality materials, the contactor is engineered for long-lasting performance and reliability in industrial environments.
- Continuous Current Rating: The contactor can handle a continuous current of up to 20A, ensuring consistent operation under demanding conditions.
- Standards Compliance: The LC1 D09 01 meets international standards including IEC 947, EN 60947, NFC 63110, VDE 0660, and BS 5424, assuring users of its safety, reliability, and quality.
- Auxiliary Contacts: Equipped with auxiliary contact rated at A 600, the contactor provides additional control options for integration into complex electrical systems.
- Electrical Ratings:
- Ith (Thermal Current): Rated at 25A for operational safety.
- Ui (Insulation Voltage): 1000V for robust electrical insulation.
- Uimp (Impulse Withstand Voltage): 8kV, ensuring high surge protection and reliability.
- Wiring Specifications:
- Supports AWG 10-18 Cu 75°C for wiring, making installation straightforward and compatible with standard industrial wiring practices.
- Torque Requirement: 7 lb.in torque for secure and reliable connection, enhancing electrical contact stability.
- Reversing Capabilities: The LC1 D09 01’s reversing function is critical for applications where motor direction needs to be changed without complex additional circuitry, improving workflow and control.
Applications:
The Telemecanique LC1 D09 01 3-pole Reversing Contactor is suitable for a variety of industrial and commercial applications, including:
- Conveyor Systems: Enables smooth and controlled reversing for conveyor belt operations.
- Cranes and Hoists: Provides secure motor reversing for lifting and lowering operations.
- Machine Tools: Ensures precise motor control for machining equipment that requires frequent directional changes.
- HVAC Systems: Supports ventilation systems requiring reversible motor operation for optimized airflow control.
Benefits of the LC1 D09 01 Contactor:
- Safety Assurance: Compliance with international standards ensures safe operation and adherence to industrial safety regulations.
- Reliable Performance: Built to withstand high current loads and frequent switching operations, enhancing overall system reliability.
- Compact Design: Its compact build allows for easy installation in control panels with limited space.
- Versatility: The contactor’s ability to operate on both 50Hz and 60Hz power supplies adds to its global usability.
