Advanced Industrial Drive Management with ABB ACW6345145600000300902 ACS600

05 Sep, 2026
Posted by: Mehul Vadher

✓ 30-Day Warranty | ✓ Free Shipping

The ABB ACW6345145600000300902 Multidrive Module ACS600 delivers industrial-grade motor control with the reliability and precision that have made ABB a trusted name in automation technology worldwide. Manufactured by ABB Oy in Finland, this robust drive module is engineered to handle the most demanding process control applications with a maximum voltage rating of 600V and output current capacity of 4300A. Its integration of NGDR-03C and NXPP-03C control cards provides the intelligent control foundation necessary for sophisticated industrial automation systems.

Modern industrial operations demand drive technology that can adapt to varying process conditions while maintaining peak efficiency. The ACS600 multidrive platform, including this ACW6345145600000300902 module, addresses these demands through its innovative common DC bus architecture and modular phase design. With a frequency output extending from 0 to 300 Hz, the module provides infinitely variable speed control that enables process optimization across an exceptionally broad operating range.

Aeliya Marine Tech understands the critical role that drive systems play in your industrial operations. Our procurement and quality assurance processes ensure that every module we offer meets stringent operational standards. This ABB ACW6345145600000300902 module comes with our standard 30-day warranty and complimentary shipping, providing you with the assurance you need to specify this component for your next project or maintenance turnaround.

Key Features & Specifications

The ABB ACW6345145600000300902 ACS600 Multidrive Module offers a comprehensive suite of features designed to address the most challenging motor control requirements in industrial automation.

600V Maximum Rating: Designed for medium-voltage industrial applications with a maximum 600V operating capacity
4300A Output Current: High-current capability supports large industrial motors in heavy-duty process applications
0-300 Hz Frequency Range: Broad speed control range enables optimization of virtually any industrial process
Advanced Control Cards: Integrated NGDR-03C (Code: 61353364D) and NXPP-03C (Code: 64008544C) for intelligent drive management
U-Phase Module Configuration: U1.2 U designation for integration as the U-phase leg in three-phase systems
Dual-Type Compatibility: Also supports ACW6441390600000300900 type (Code: 64277456) at 1156A
Finnish Manufacturing: Built in Finland by ABB Oy to rigorous European quality and safety standards

Technical Specifications

Specification	Details
Manufacturer	ABB Oy
Product Series	ACS600 Multidrive Modules
Type Code	ACW6345145600000300902
Module Code	64310810
Alternate Code	64277456
Maximum Voltage	600V
Output Voltage (U2)	3~0...U1V
Rated Current (I2N)	4300A
Secondary Current	1156A (ACW6441390600000300900)
Frequency Range (F2)	0..300 Hz
Phase Configuration	U-Phase Module (U1.2 U)
Controller Card	NGDR-03C (Code: 61353364D)
Processor Card	NXPP-03C (Code: 64008544C)
Country of Origin	Finland
Condition	Used

Applications & Use Cases

The ABB ACW6345145600000300902 module's combination of 600V maximum voltage, 4300A current capacity, and 0-300 Hz frequency control makes it suitable for an exceptionally wide range of industrial applications across multiple sectors.

Steel & Metal Processing

Hot and cold rolling mills, slab casters, and strip processing lines require drive systems that can deliver high torque at variable speeds under extreme operating conditions. The 600V rating and 4300A capacity of this module are well-matched to the large motors used in primary metals processing, while its precise speed control ensures product quality and dimensional accuracy.

Marine & Offshore Engineering

Offshore platforms, drilling rigs, and dynamically positioned vessels rely on ACS600 multidrive systems for propulsion, positioning, and process equipment. The 600V maximum rating is compatible with standard marine electrical systems, while the module's robust construction ensures reliable operation in the salt-laden, high-vibration marine environment.

Water Treatment & Distribution

Large raw water intake pumps, high-lift pumping stations, and wastewater treatment aeration blowers require drives that can operate efficiently across a wide flow range. The 0-300 Hz frequency range enables precise flow matching to demand conditions, reducing energy consumption and extending equipment life compared to throttled constant-speed operation.

Wind Tunnel & Testing Facilities

Aerospace and automotive testing facilities use large variable-speed fans to generate controlled airflow conditions. The precise speed control and high power capability of the ACW6345145600000300902 module make it ideal for these applications where airflow accuracy directly impacts test validity.

⚠ Limited Units Remaining

Stock is limited on this ABB ACW6345145600000300902 Multidrive Module. Order today to ensure availability for your project timeline.

View Details

Why Choose the ABB ACW6345145600000300902 ACS600 Module

The ACW6345145600000300902 module offers distinct advantages that make it a compelling choice for industrial drive applications requiring high voltage capability and precise control.

600V Voltage Capability

The 600V maximum voltage rating positions this module for medium-voltage industrial applications that exceed the capabilities of standard low-voltage drives. This expanded voltage range enables direct connection to higher-voltage distribution systems without requiring step-down transformers, reducing installation complexity and cost.

NGDR-03C Advanced Drive Control

The NGDR-03C drive controller card represents ABB's advanced control technology, delivering sophisticated motor control algorithms that optimize performance across the entire operating range. Combined with the NXPP-03C processor card, this control system provides real-time monitoring, adaptive parameter tuning, and comprehensive fault diagnostics that simplify commissioning and maintenance.

Proven Multidrive Economics

The ACS600 multidrive architecture delivers compelling economic advantages through shared DC bus topology, reduced component count compared to multiple standalone drives, simplified cabling, and energy regeneration capabilities. For facilities with multiple large motors, these advantages can result in total system costs that are significantly lower than equivalent standalone drive installations.

Compatibility & Integration

Proper integration of the ACW6345145600000300902 module requires attention to electrical, mechanical, and control compatibility requirements.

ACS600 Multidrive System Requirements

This U-phase module (U1.2 U) is designed for integration into a complete ACS600 multidrive system. It requires compatible V-phase and W-phase modules, a common DC bus power supply, and the system control unit. The Code: 64277456 type modules provide complementary functionality for balanced three-phase operation within the multidrive configuration.

Electrical Infrastructure

The 600V maximum rating and 4300A current capacity require appropriately specified electrical infrastructure. Power distribution, protection devices, and cabling must be rated for the module's electrical characteristics. Qualified electrical engineers should design the power system in accordance with industrial automation best practices and applicable electrical codes.

Environmental Specifications

Installation environment must be maintained within ABB's specified temperature, humidity, and cleanliness parameters. The module's thermal management system requires adequate ventilation to dissipate the heat generated during operation. Enclosed installations may require supplemental cooling to maintain acceptable operating temperatures.

Maintenance & Support

Maintaining optimal performance from your ABB drive module requires adherence to recommended maintenance practices and access to responsive technical support.

Preventive Maintenance Schedule

ABB recommends establishing a preventive maintenance schedule that includes regular inspection of power connections, heat sink cleaning, cooling system verification, and control card diagnostics. Thermal imaging of power connections during loaded operation can identify developing issues before they cause failures. Maintaining detailed maintenance records supports trend analysis and predictive maintenance initiatives.

Aeliya Marine Tech Commitment

Aeliya Marine Tech is committed to your long-term operational success. Our 30-day warranty on this module provides protection against unexpected issues, while our knowledgeable support team can assist with technical questions and integration guidance. We understand that industrial drive system downtime is costly, and we work diligently to help you maintain continuous operation.

Frequently Asked Questions

Q1: What is the maximum voltage rating of this module?

The ABB ACW6345145600000300902 module has a maximum voltage rating of 600V, making it suitable for medium-voltage industrial applications that exceed standard low-voltage drive capabilities.

Q2: What phase configuration does this module provide?

This module is configured as a U-phase module with designation U1.2 U. It is designed to work with companion V-phase and W-phase modules to provide balanced three-phase power output in an ACS600 multidrive system.

Q3: What control cards are integrated into this module?

The module includes the NGDR-03C drive controller (Code: 61353364D) and the NXPP-03C processor card (Code: 64008544C). These cards provide advanced motor control, protection functions, and communication capabilities.

Q4: What condition is this module in and what warranty is included?

This module is offered in used condition and has been inspected by Aeliya Marine Tech to verify operational integrity. It is covered by our 30-day warranty against functional defects, and all orders include free shipping.

Q5: Where is this module manufactured?

This ABB module is manufactured in Finland by ABB Oy, ABB's Finnish subsidiary. Finnish manufacturing is renowned for high quality standards and attention to engineering detail.

Q6: Can this module be used for energy regeneration applications?

Yes, when installed in a properly configured ACS600 multidrive system with a regenerative power supply unit, this module supports energy regeneration during motor deceleration. The regenerated energy can be fed back to the power grid or shared with other drives on the common DC bus.
