A Closer Look at ABB ACW6441390600000300900 Drive Technology

07 Sep, 2026
Posted by: Mehul Vadher

✓ 30-Day Warranty | ✓ Free Shipping

The ABB ACW6441390600000300900 Multidrive Module represents the pinnacle of ABB's ACS600 drive technology, delivering exceptional power handling and control precision for the most demanding industrial automation applications. Manufactured by ABB Oy in Finland, this high-performance drive module combines a 4300A/1156A dual current rating with a comprehensive 0-300 Hz frequency range to address virtually any large-scale motor control challenge. Its integration of proven NGDR-03C and NXPP-03C control cards ensures that this module delivers not just raw power, but intelligent, adaptive motor control that optimizes process performance.

Industrial facilities that cannot afford unplanned downtime specify ABB ACS600 multidrive modules for their most critical motor control applications. The ACW6441390600000300900 module's 600V maximum rating makes it suitable for medium-voltage industrial systems, while its W-phase configuration (U1.3 W) enables seamless integration into balanced three-phase multidrive installations. Whether deployed in marine propulsion systems, metals processing lines, or continuous manufacturing processes, this module delivers the reliability and performance that industrial operators depend on.

At Aeliya Marine Tech, we recognize that procuring industrial drive components is a critical decision that impacts your operational capability for years to come. Every module we offer undergoes careful evaluation to ensure it meets our quality standards. This ABB ACW6441390600000300900 Multidrive Module is backed by our comprehensive 30-day warranty and free worldwide shipping, giving you the confidence to specify this component for your most demanding applications.

Key Features & Specifications

The ABB ACW6441390600000300900 ACS600 Multidrive Module offers an impressive array of technical capabilities that establish it as a leading solution in industrial drive technology.

Dual Current Ratings: 4300A primary and 1156A secondary current capability for flexible application across power ranges
600V Maximum Rating: Medium-voltage capability for demanding industrial power distribution systems
Comprehensive Frequency Control: 0-300 Hz output range supports infinitely variable speed control
W-Phase Configuration: U1.3 W designation for the W-phase leg in three-phase multidrive systems
Intelligent Control System: NGDR-03C (Code: 61353364D) and NXPP-03C (Code: 64008544C) cards included
Robust Construction: 59 Kg weight reflects heavy-duty industrial-grade component selection
Finnish Manufacturing: Produced by ABB Oy in Finland under ISO-certified quality management

Technical Specifications

Specification	Details
Manufacturer	ABB Oy
Product Series	ACS600 Multidrive Modules
Type Code	ACW6441390600000300900
Alternate Code	64277456
Compatible Type	ACW6345145600000300902
Module Code	64310810
Maximum Voltage	600V
Output Voltage (U2)	3~0...U1V
Primary Current (I2N)	4300A
Secondary Current (I2N)	1156A
Frequency Range (F2)	0..300 Hz
Phase Configuration	W-Phase Module (U1.3 W)
Controller Card	NGDR-03C (Code: 61353364D)
Processor Card	NXPP-03C (Code: 64008544C)
Country of Origin	Finland
Weight	59 Kg
Condition	Used

Applications & Use Cases

The ABB ACW6441390600000300900 module's exceptional power handling and control precision make it suitable for an extensive range of industrial applications where motor control performance directly impacts productivity and product quality.

Continuous Process Manufacturing

Industries such as paper and pulp, cement, and chemicals operate continuous processes where any interruption results in significant financial losses. The ACW6441390600000300900 module's high reliability and precise speed control ensure that these processes operate at optimal efficiency around the clock. The 4300A current rating accommodates the large motors that drive continuous production equipment, while the 0-300 Hz range enables precise process control across all operating conditions.

Test Rigs & Dynamometers

Engine testing facilities, transmission test rigs, and powertrain dynamometers require drive systems that can precisely control motor speed and torque to simulate real-world operating conditions. The ACW6441390600000300900 module's precise frequency control and high current capability make it ideal for these demanding test and measurement applications.

Renewable Energy Systems

Pumped-storage hydroelectric facilities and tidal energy systems require bi-directional drive systems capable of operating in both motoring and generating modes. The ACS600 multidrive platform's common DC bus architecture and regenerative capability make it well-suited for these energy storage and conversion applications.

Port & Terminal Operations

Container cranes, ship loaders, and bulk material handling equipment at major ports require drive systems that can deliver high starting torque and precise positioning capability. The 4300A rating and W-phase configuration of this module provide the power and control necessary for these demanding material transfer operations.

⚠ Only 1 Unit in Stock – Order Immediately

This ABB ACW6441390600000300900 Multidrive Module is the last available unit. Secure it today for your critical drive system needs.

View Details

Why Choose the ABB ACW6441390600000300900 Multidrive Module

The ACW6441390600000300900 module delivers compelling advantages that distinguish it from alternative drive solutions in the marketplace.

Dual-Current Versatility

The 4300A/1156A dual rating provides exceptional flexibility in application. Engineers can deploy this module in high-power applications requiring the full 4300A capacity, or in lower-power systems where the 1156A rating is sufficient. This versatility reduces spare parts inventory requirements and simplifies maintenance procedures by standardizing on a single module type across multiple applications.

Integrated Protection Intelligence

The NGDR-03C and NXPP-03C cards provide comprehensive protection against the electrical fault conditions that can damage drive systems and connected motors. Overcurrent protection, thermal monitoring, ground fault detection, and voltage transient protection are all managed by the integrated control system, safeguarding your valuable industrial equipment from costly damage.

Decades of Field-Proven Reliability

The ACS600 platform has accumulated millions of field operating hours across every industrial sector and geographic region. This extensive operational history has validated the design's reliability and durability under real-world conditions that laboratory testing cannot fully replicate. When you select an ACS600 module, you are choosing a design that has proven its capabilities in the most demanding applications imaginable.

Compatibility & Integration

Successful deployment of the ACW6441390600000300900 module requires careful attention to system-level compatibility requirements.

Multidrive System Architecture

As a W-phase module (U1.3 W), this unit is designed for integration into a three-phase ACS600 multidrive system. It must be paired with compatible U-phase and V-phase modules to produce balanced three-phase output power. The common DC bus connects all modules in the system, enabling energy sharing and coordinated control through the central system controller.

Type Code Compatibility

The ACW6441390600000300900 type (Code: 64277456) is fully compatible with ACW6345145600000300902 type modules (Code: 64310810) within the ACS600 system. This cross-compatibility enables system designers to mix module types within a single multidrive installation to optimize performance for specific application requirements.

Power Distribution Requirements

The 4300A current rating and 600V maximum voltage require power distribution infrastructure rated for these electrical characteristics. Protection devices, buswork, and cabling must be properly specified to handle the module's output capabilities. Installation should be performed by qualified electrical contractors in accordance with industrial automation standards and local electrical codes.

Maintenance & Support

Protecting your investment in this high-performance drive module requires a proactive approach to maintenance and access to responsive technical support.

Condition Monitoring

Modern maintenance practices increasingly rely on condition monitoring to predict failures before they occur. The ACS600's integrated diagnostics provide valuable data on module health, including thermal trends, power semiconductor status, and control card functionality. Analyzing this data enables transition from time-based to condition-based maintenance, reducing costs while improving reliability.

Aeliya Marine Tech Warranty & Service

This ABB ACW6441390600000300900 module is covered by Aeliya Marine Tech's 30-day warranty, providing protection against functional defects that may become apparent after installation. Our technical support team is available to assist with installation guidance, compatibility verification, and operational questions. We are committed to ensuring your complete satisfaction with every product we sell.

Frequently Asked Questions

Q1: What do the dual current ratings (4300A/1156A) mean?

The dual ratings indicate the module's versatility. It operates at 4300A in its primary ACW6441390600000300900 configuration and at 1156A when functioning with ACW6345145600000300902 type modules. This flexibility enables use across a wide range of application power requirements.

Q2: What does the 600V maximum rating signify?

The 600V maximum rating indicates this module is designed for medium-voltage industrial applications, enabling direct connection to higher-voltage distribution systems without step-down transformers.

Q3: What is the W-phase (U1.3 W) configuration?

The U1.3 W designation identifies this as a W-phase module that generates the W-phase leg of a three-phase power output. It works with companion U-phase and V-phase modules to deliver balanced three-phase power to connected motors.

Q4: What condition is this module in?

This module is sold in used condition. Aeliya Marine Tech inspects all used products to verify operational integrity before offering them for sale. The 30-day warranty provides additional assurance of functional reliability.

Q5: Are control cards included with the module?

Yes, the NGDR-03C controller card (Code: 61353364D) and NXPP-03C processor card (Code: 64008544C) are included. These cards are integral to the module's control and protection functions.

Q6: How much does the module weigh?

The module weighs 59 Kg (approximately 130 lbs). Proper material handling equipment and lifting procedures should be used during installation and removal to ensure technician safety and prevent damage to the module.
