| Specification | Details |
|---|---|
| Brand | Schneider Electric India Pvt Ltd / Merlin Gerin |
| Product Type | Circuit Breaker (Crimped Lug/Busbar) |
| Configuration | 3P Circuit Breaker and Switch-disconnector |
| Series | Compact NSXm |
| Model | NSXm160F |
| Product Reference | LV426357 |
| Rated Insulation Voltage (Ui) | 800 V |
| Impulse Withstand Voltage (Uimp) | 8 kV |
| Frequency | 50/60 Hz |
| Standard Compliance | IEC/EN 60947-2 |
| Operating Temperature | 40°C |
| Category | Category A |
| Rated Current (In) | 100A |
| Adjustable Current (Ir) | 70/100 A |
| Instantaneous Tripping Current (Ii) | 1250A |
| Breaking Capacity | 36KA at 380/415V |
| Thermal Protection Setting | Tm100D |
| Date Code | TC-2017-W11-1 |
| Description | Breaker NSXm 36KA Tm100D 3P Busbar |
| Country of Manufacture | China |
| Weight | 1.150 kg |
Schneider Electric LV426357 Circuit Breaker is a three-pole (3P) switch-disconnector generally used in industrial and commercial applications. Due to its high rating of 100A, this circuit breaker ensures safety while working with different circuits against voltage fluctuations in a system. Compact NSXm series is created with respect for both space and reliability, hence best suited for using in densely packed electrical systems. This breaker integrates advanced protection features with a strong construction to operate safely in challenging environments and to provide optimum performance. Additionally, it offers the option for crimped lug/busbar connections.
Key Features:
- 100A Rated Current: Built to handle demanding applications, the LV426357’s 100A current rating makes it suitable for medium to large-scale industrial and commercial electrical systems.
- Three-Pole Design (3P): This 3P configuration offers enhanced protection by isolating all three phases, making it ideal for unbalanced loads and three-phase systems where comprehensive isolation is essential.
- High Short-Circuit Breaking Capacity: With a short-circuit breaking capacity of 36KA at 380/415V, this circuit breaker provides robust protection against electrical faults, reducing the risk of damage to equipment and wiring.
- Compact NSXm Series: Part of the Compact NSXm line, the LV426357 has a space-saving design that maximizes installation flexibility without compromising on power and protection.
- Crimped Lug and Busbar Connections: Equipped for both crimped lug and busbar connections, this breaker allows for versatile installation in different circuit configurations.
- Impulse Withstand Voltage (Uimp): The 8kV impulse withstand rating provides added durability against transient overvoltages, enhancing system protection and reliability.
- IEC/EN 60947-2 Compliance: This breaker complies with IEC/EN 60947-2 standards, guaranteeing that it meets international safety and performance standards, making it suitable for global applications.
- Category A: The LV426357 falls into Category A, ensuring fast and reliable disconnection, which is ideal for short-circuit protection in industrial environments.
Product Specifications:
- Brand: Schneider Electric India Pvt Ltd / Merlin Gerin
- Product Type: Circuit Breaker (Crimped Lug/Busbar)
- Configuration: 3P Circuit Breaker and Switch-disconnector
- Series: Compact NSXm
- Model: NSXm160F
- Product Reference: LV426357
- Rated Insulation Voltage (Ui): 800V
- Impulse Withstand Voltage (Uimp): 8kV
- Frequency: 50/60 Hz
- Standard Compliance: IEC/EN 60947-2
- Operating Temperature: 40°C
- Category: Category A
- Rated Current (In): 100A
- Adjustable Current Range (Ir): 70/100A
- Instantaneous Tripping Current (Ii): 1250A
- Short-Circuit Breaking Capacity: 36KA at 380/415V
- Thermal Protection Setting: Tm100D
- Date Code: TC-2017-W11-1
- Additional Description: Breaker NSXm 36KA Tm100D 3P Busbar
- Barcode: 3 606481 175038
- Country of Manufacture: China
- Weight: 1.150 kg
Applications:
The Schneider Electric LV426357 Circuit Breaker is an excellent choice for a variety of industrial, commercial, and infrastructure settings that demand reliable circuit protection. Typical applications include:
- Industrial Facilities: Provides dependable circuit protection in manufacturing plants and equipment, safeguarding machinery and ensuring consistent operation.
- Commercial Buildings: Ideal for office complexes, malls, and other large commercial structures where stable power distribution and protection are critical.
- Infrastructure and Utility Projects: Suitable for infrastructure projects where dependable circuit management is essential for operational safety and reliability.
- Renewable Energy Systems: Commonly used in solar and wind energy systems for overcurrent protection, especially in systems with significant power fluctuations.
Why Choose the Schneider Electric LV426357?
The LV426357 by Schneider Electric provides a vast package of solutions for professionals, as it covers, amongst others, an industrial-grade breaker with reliable performance. It also offers high short circuit capacity, flexibility in connectivity options, and compliance with IEC/EN 60947-2 standards for demanding environments. With the quality and innovation that has made Schneider Electric famous, it's designed to bring together the best of power, protection, and durability in a compact form factor, thereby making it perfect for new installations and retrofits.
