Yokogawa ANR10D Node Interface Unit with I/O Modules for CENTUM DCS Systems

23 Jul, 2026
Posted by: Mehul Vadher

Condition: Used

✓ 30-Day Warranty | ✓ Free Shipping

Distributed Control Systems (DCS) form the nervous system of modern process plants, coordinating thousands of input and output points across sprawling industrial facilities. The Yokogawa ANR10D Node Interface Unit is a cornerstone component of the renowned Yokogawa CENTUM DCS platform, serving as the intelligent gateway that connects field I/O modules to the system's control network. This particular unit comes fully equipped with an extensive complement of I/O modules, making it a ready-to-deploy solution for system expansions, replacements, or new installations.

At Aeliya Marine Tech, we understand that DCS components are mission-critical investments that must integrate seamlessly with existing infrastructure. The ANR10D we offer is a quality Used unit that has been sourced and inspected to verify operational readiness. With its comprehensive module configuration including analog input, analog output, digital I/O, and communication modules, this node interface unit provides exceptional value for process control engineers who need a complete, pre-configured DCS node. Every unit is backed by our 30-day warranty and ships free, ensuring your project stays on schedule and within budget.

Key Features & Specifications

The Yokogawa ANR10D Node Interface Unit delivers a comprehensive set of features that make it an indispensable component of the CENTUM DCS ecosystem. Its robust design and extensive I/O capability support the most demanding process control applications.

CENTUM DCS Integration: Native node interface unit for Yokogawa's industry-leading CENTUM distributed control system
Comprehensive I/O Package: Pre-loaded with 10 I/O modules covering analog input, output, digital I/O, and communication functions
220-240 VAC Operation: Standard industrial voltage input with 50/60Hz compatibility for global deployment
Hazardous Area Rated: CL.I, Div.2, Groups A,B,C,D classification for installation in classified locations
260 VA Power Capacity: Substantial power rating supports full I/O module loading without performance degradation
Component Number FCSAFV10D-F1: Factory-registered component number ensures traceability and compatibility
Style S1 Configuration: Verified style designation for correct system software configuration

Technical Specifications

Specification	Details
Product Name	Yokogawa ANR10D Node Interface Unit with I/O Modules
Manufacturer	Yokogawa Electric Corporation
Model	ANR10D
DCS Platform	CENTUM
Style	S1
Serial Number	C2K606198 1021
Supply Voltage	220-240 VAC, 50/60Hz
Power Rating	260 VA
Suffix	-420 / NDEL
Component Number	FCSAFV10D-F1
Hazardous Classification	CL.I, Div.2, Groups A,B,C,D
Analog Input Module	AAB841-S00 S2
Analog Input Module 2	AAV141-S00 S2
Temperature Module	ATM4A-00 S1
TC Input Module	ATK4A-00 S1
RTD Module	AAT145-S00 S1
RTD Module 2	AAR145-S00 S1
Digital Input Module	ADV161-P00 S2
Digital Output Module	ADV561-P00 S2
Communication Module	EB501-10 S2
Power Supply Module	PW482-10 S2
Condition	Used

Applications & Use Cases

The Yokogawa ANR10D Node Interface Unit with its comprehensive I/O module complement serves a wide range of process industries where the CENTUM DCS is the control platform of choice. Its versatility and reliability have made it a standard component in some of the world's most critical industrial installations.

Petrochemical & Refining Operations

Refineries and petrochemical plants use CENTUM DCS with ANR10D nodes to control distillation columns, reactors, heat exchangers, and storage facilities. The included analog input modules (AAB841, AAV141) handle 4-20mA signals from pressure, temperature, and flow transmitters, while the digital I/O modules (ADV161, ADV561) manage pump starts, valve position commands, and alarm annunciation. The temperature modules (ATM4A, ATK4A, AAT145, AAR145) support thermocouple and RTD inputs for the precise temperature measurements essential to reaction control and fired heater management.

Power Generation Facilities

Fossil fuel and combined cycle power plants rely on CENTUM DCS for boiler control, turbine protection, and emissions management. The ANR10D's mix of analog and digital I/O supports the full range of power plant instrumentation, from drum level transmitters to burner management system position switches. The EB501-10 communication module enables integration with intelligent field devices using FOUNDATION Fieldbus or HART protocols, reducing wiring costs while expanding diagnostic capabilities.

Pharmaceutical Manufacturing

Pharmaceutical facilities require precise control of batch reactors, clean-in-place systems, and environmental conditions. The ANR10D's accurate analog input modules provide the measurement resolution needed for tight control loops, while the PW482-10 power supply ensures stable operation during critical batch phases. The hazardous area classification supports installation in solvent-handling areas where explosive atmospheres may be present.

Marine & Offshore Control Systems

FPSO vessels, LNG carriers, and offshore platforms increasingly specify Yokogawa CENTUM for topside process control. The ANR10D's robust construction and marine-grade component selection ensure reliable operation in the vibration-prone, salt-laden atmosphere of offshore installations. Its 220-240 VAC input is compatible with international marine electrical standards, and the CL.I, Div.2 rating supports installation in gas-handling areas without additional explosion-proof enclosures.

⚠ Only 1 Unit in Stock

This fully-loaded Yokogawa ANR10D with complete I/O module set is available as a single unit. Secure it today for your CENTUM DCS project with free shipping and 30-day warranty from Aeliya Marine Tech.

View Details

Why Choose the Yokogawa ANR10D

When selecting DCS node hardware, control engineers evaluate platform compatibility, I/O density, reliability metrics, and total cost of ownership. The ANR10D excels across all these dimensions, making it the preferred choice for CENTUM-based control systems.

Complete Pre-Configured Solution

Unlike bare node units that require separate procurement and installation of I/O modules, this ANR10D comes fully equipped with 10 modules covering the most commonly needed input and output types. This saves engineering time, reduces procurement complexity, and ensures that all modules are correctly seated and ready for commissioning. For project teams facing tight deadlines, this ready-to-deploy configuration can accelerate installation schedules by weeks.

Yokogawa Quality & Reliability

Yokogawa Electric Corporation is consistently ranked among the most reliable DCS suppliers in the industry, with mean time between failure (MTBF) metrics that set the benchmark for process control hardware. The ANR10D inherits this quality pedigree, featuring redundant power paths, diagnostic LED indicators, and hot-swappable module design that maximizes system availability.

Hazardous Area Certification

The CL.I, Div.2, Groups A,B,C,D classification allows the ANR10D to be installed in classified locations without the cost and complexity of purged enclosures or intrinsically safe barriers for every signal. This certification reduces installation costs and simplifies compliance with NEC and API requirements for electrical equipment in hazardous locations.

Aeliya Marine Tech DCS Expertise

Our team has deep experience with Yokogawa CENTUM systems across multiple industry sectors. We can assist with node configuration questions, I/O module selection, and compatibility verification to ensure your ANR10D integrates correctly with your existing control network. This expertise, combined with our warranty and free shipping, makes Aeliya Marine Tech your ideal partner for DCS component procurement.

Compatibility & Integration

Successful integration of the ANR10D into a CENTUM DCS requires attention to hardware, software, and network configuration. The following guidance helps ensure a smooth installation.

CENTUM Software Compatibility

The ANR10D with Style S1 and suffix -420/NDEL is compatible with specific versions of the CENTUM CS 3000 and CENTUM VP software platforms. Verify your current system software revision against Yokogawa's hardware compatibility matrix before installation. Aeliya Marine Tech can provide the style and suffix information needed for this verification.

Network Integration

The node interface unit connects to the CENTUM control network via the integrated highway interface. Network configuration requires assignment of a unique node address and verification of cable continuity between the ANR10D and the nearest network switch or repeater. The FCSAFV10D-F1 component number should be referenced when ordering replacement network interface cards.

I/O Module Configuration

Each I/O module in the ANR10D must be configured in the CENTUM engineering station with correct channel assignments, signal types, and engineering ranges. The module style codes (S1, S2) indicate specific hardware revisions that may have different feature sets. Refer to the Yokogawa I/O Module Reference Manual for detailed configuration procedures for each module type.

Maintenance & Support

Regular maintenance of DCS node units is essential for ensuring long-term system availability and preventing unplanned shutdowns. The ANR10D's diagnostic capabilities and modular design simplify maintenance activities and minimize mean time to repair (MTTR).

Preventive Maintenance Schedule

Inspect the ANR10D annually for dust accumulation on module heat sinks, secure seating of all I/O modules, and tightness of power and ground connections. Check the PW482-10 power supply module's output voltages against specification, and verify that all status LEDs indicate normal operation. Clean air filters in the enclosure monthly and replace them quarterly to maintain adequate cooling airflow.

Aeliya Marine Tech Support Services

Your ANR10D purchase includes Aeliya Marine Tech's standard 30-day warranty and access to our technical support team. We can assist with pre-installation compatibility checks, configuration guidance, and troubleshooting support. For larger DCS projects, we can coordinate with Yokogawa-certified system integrators to provide comprehensive engineering services.

Frequently Asked Questions

Q1: What DCS platform is the ANR10D compatible with?

The ANR10D is a node interface unit for the Yokogawa CENTUM distributed control system platform. It is compatible with CENTUM CS 3000 and CENTUM VP systems, subject to software version verification.

Q2: What I/O modules are included with this unit?

This ANR10D includes 10 I/O modules: AAB841-S00 S2 (analog input), AAV141-S00 S2 (analog input), ATM4A-00 S1 (temperature), ATK4A-00 S1 (TC input), AAT145-S00 S1 (RTD), AAR145-S00 S1 (RTD), ADV161-P00 S2 (digital input), ADV561-P00 S2 (digital output), EB501-10 S2 (communication), and PW482-10 S2 (power supply).

Q3: What is the hazardous area rating?

The ANR10D is rated for CL.I, Div.2, Groups A,B,C,D locations, allowing installation in classified hazardous areas without additional explosion-proof enclosures.

Q4: What power supply does the ANR10D require?

The unit requires 220-240 VAC at 50/60Hz with a power rating of 260 VA. This is standard industrial voltage available in most process control facilities worldwide.

Q5: Is this unit new or used?

This ANR10D is in Used condition and has been inspected by Aeliya Marine Tech. It comes with our 30-day warranty and free shipping.

Q6: Can individual I/O modules be replaced?

Yes, the ANR10D supports hot-swappable I/O module replacement on most module types, allowing maintenance without shutting down the entire node. Specific hot-swap capabilities vary by module type and system software version.

Q7: Does Aeliya Marine Tech provide CENTUM integration support?

Aeliya Marine Tech provides general compatibility guidance and pre-installation verification. For detailed CENTUM engineering and commissioning services, we can refer you to Yokogawa-certified system integrators in your region.
